D-subminiature
Connectors
Introduction
Information
The D-subminiature is one of the most popular styles of connectors in the I/O category. It is used in computer,
telecom, datacom, medical, and test instrumentation applications as well as in the military and aerospace fields.
Types of D-subminiature connectors manufactured by Cinch
?
?
Printed Circuit Board connectors:
- Vertical connectors for panel mounting with Dip Solder PC tails.
- Right-Angle connectors for board mounting with Dip Solder PC tails.
Wire Termination connectors for cable assemblies or wire harnesses:
- Crimp and Poke connectors.
- Solder Cup connectors.
- Insulation Displacement connectors IDC S to terminate discrete wire or flat cable.
- Wire Wrap connectors.
How to read this section
?
The information pages provide standard data common to all D-subminiature connectors. These include:
-
-
-
-
-
-
D-subminiature contact arrangements - see page 4-5.
Panel mounting specifications/hardware - see page 4-6.
D-subminiature shell dimensions - see page 4-7.
D-subminiature and combo D layouts - see pages 4-5, 4-8 thru 4-10, and 4-56.
General Performance Specifications - see page 4-2.
PCB thickness chart - see page 4-8.
?
?
?
D-subminiature pages are grouped by series. A series is a family of connectors with a similar performance level.
Each series shares a set of features and specifications, from economical and commercial grade product to
high-reliability and military connectors. Each series begins with a page outlining general features and
specifications of connectors, followed by the pages on individual connectors with drawings or features specific
to that connector. Drawings reflect clarifications of dimensions not called out in the information pages of this
catalog. The features of each series can be found in the chart on page 4-4.
Accessories including backshells, junction shells, and hoods as well as hardware can be found on pages 4-80
thru 4-99.
Termination tooling for Cinch connectors can be found at the end of the D-subminiature section of this
catalog on pages 4-100 thru 4-104.
Call Toll Free: 1 (800) 323-9612
4-1
